The INT-SZ-GR code lock is a small device designed to work with INTEGRA and CA-64 control panels. It makes possible control of access to the room or area, entry to which is restricted by a door with electrically-operated lock. It can also be used for access control over other devices provided with this type of lock (gates, gratings, trapdoors, etc.).
INT-SZ-GR has a door status monitoring input, tamper switch and three colored LEDs to indicate the door status / door opening (the door opening is additionally signaled acoustically). Using the correspondingly marked keys, you can trigger the three alarms – PANIC, FIRE and AUX – directly from the keypad. The keys are backlit for comfortable use even in low light conditions.
The code lock is available in two backlight color versions: INT-SZ-GR (green) and INT-SZ-BL (blue).
- LEDs for door state indication
- keypad hold-down PANIC, FIRE and AUX alarms
- buzzer for door left open indication
- relay for electromagnetic lock/electric strike
- door control input
