Introducing
HYBRID 128
a hybrid control panel with built-in ETHM and Wi-Fi modules, supporting ABAX 2 wireless devices
HYBRID 128 Plus
HYBRID and WIRE offer everything that defines BE WAVE: simple device configuration, easy automation setup, and intuitive everyday operation. They also introduce the reliable wired communication valued by SATEL installers, now implemented in the RS-485 standard for the first time.
The new control panels support a single RS-485 bus line that can be used to connect bus detectors, sirens, and other compatible SATEL devices. This solution simplifies system wiring and reduces the number of cables routed directly to the control panel. Adding new devices is easier and does not require separate wiring lines for each system component.
Communication is based on the RS-485 standard using the proprietary SATEL BUS protocol, enabling advanced diagnostics of data transmission between devices and the alarm control panel. This makes system configuration easier, speeds up installation commissioning, and streamlines troubleshooting when needed. Another key advantage of this solution is the ability to remotely update most devices connected to the bus.
The bus line can be up to 1,200 m long, with the option to extend it further, while communication between devices on the bus is fully encrypted using the AES-128 standard.
BE WAVE uses a simple if–then–else logic sequence for creating automation rules. As a result, even complex automations can be configured intuitively, without the need to build complicated logical dependencies between zones and outputs.
HYBRID and WIRE support the TPH-2 wired digital detector via the RS-485 bus. This single device can measure temperature, atmospheric pressure, and humidity levels in a room. The collected data can then be used to create automation scenarios.
We are introducing a completely new category to the SLIM LINE motion detector portfolio: ceiling detectors. The range includes more than 20 new devices, both wired and wireless, designed for flush-mounted and surface-mounted installation. The ceiling models offer the same wide range of features already known from the SLIM LINE wall-mounted detectors, while maintaining the distinctive design and high-quality motion detection performance.
Selected models also support bus communication.
The wireless ceiling detector models operating within the ABAX 2 system are also compatible with the BE WAVE system. We continue to expand the portfolio of devices supported by BE WAVE controllers, and now also BE WAVE control panels, to give installers complete freedom in designing smart & safe systems.
SLIM LINE wall-mounted detectors:
now also available in bus versions
The new SLIM LINE models are compatible with the BE WAVE Hybrid and BE WAVE Wire control panels.
We know how important extensive integration capabilities are for installers. That is why we are introducing a new product: the AUT-200 universal wireless transmitter. This compact device enables the connection of wired detectors and other devices to the ABAX 2 system controller. Equipped with three NC inputs, the AUT-200 makes the integration of wired solutions quick and easy, without giving up the advantages of wireless technology.
We are expanding our range of 868 MHz wireless devices with the ASW-220, a new in-wall dual-channel controller designed for controlling 230 V AC electrical devices. Unlike its sister model, the ASW-210, the ASW-220 additionally features energy consumption monitoring for connected devices.
ASW-220 is also supported by the BE WAVE system, where it is available as the Smart 2-CH Relay PM.
Our Technical Experts are ready to provide you with full support. Log in to the SATEL Support Service and submit a ticket.
